Up to 1 Gigabit Speeds for Faster Data Transfer
- Gigabit Uplink and Downlinks
- Port Isolation
- PoE++ 90W Port
ScatterBox Gigabit PoE switches have been specifically tailored for powering and connecting IP CCTV cameras to a network thanks to their high speed capacity and high load capacity.
ScatterBox Gigabit PoE switches have been specifically tailored for powering and connecting IP CCTV cameras to a network thanks to their high speed capacity and high load capacity.
Not just a distributor, they work in 2 directions firstly by taking a network connection input and distributing power across its 8 ports to connected IP cameras or devices but in reverse too by carrying the video signal from all the connected cameras back into a single network cable for reproduction elsewhere on the network.
The units add extra flexibility to a network infrastructure thanks to 100 metre run capabilities both in and out of them.
*These PoE switches feature PoE++ ports (90W):
- POE608 - Port 1 PoE ++ 90W; Ports 2 - 8: 30W.
Feature Packed Gigabit Switches!
- Gigabit Speeds - Up to 1GB for fast transmission of data over the network
- High Load Capacity - Up to 300W per device and up to 30W per port
- Virtual LAN (VLAN) - Extra security as downlinks can only talk to the uplinks and not each other
- Multiple Uplinks - Connect to more upstream devices such as NVRs and Routers simultaneously
8 Port Switch - POE608
A 10 port Gigabit switch, 2 up links and 8 down links; ideal for connecting directly to an NVR for a local system or for networking via a router.
Each RJ45 port can supply up to 30W individually or 120W over the whole unit.
POE608 | |
---|---|
Uplinks | 2 |
Downlinks | 8 |
Bandwidth | 10Mbps / 100Mbps / Gigabit |
VLAN | EPoE / VLAN / Standard |
Max Load | 120W |
Max Port Load | 30W |
Power | 240V AC (Lead Supplied) |
PSU | Built-in |
Mount | Desk |
Use | Internal Use Only |
Dimensions | W210 x D155 x H34mm |
PoE ++ ports | Port 1 has PoE ++ 90W; the other ports are 30W max. |
- Technology:
- IP
- Switch:
- PoE
- Network Accessory:
- Switch
