TVT IP 8MP Face Rec EYEBALL 2.8-12mm
Varifocal IP Eyeball Camera with Built-in Face Recognition & Intelligent Analytics
- Face Recognition
- Up to 50m IR Range
- AI Algorithms Reduce False Triggers
- Line Crossing & Intrusion Detection
Versatile eyeball camera with powerful IR light and built-in face recognition.
This powerful 4K bullet camera has built-in face recognition and an IR range of up to 50m.
The TVT E series cameras, E standing for Enhanced, such as this one utilise deep learning algorithms so that they can offer advanced AI functions such as face recognition, video meta data, crowd density detection, heat mapping, target counting and much more.
Handling face recognition in the camera takes the burden off the NVR so that it is free to process other AI features. As standard the TVT NVRs support face recognition on 2 channels simultaneously. Having a camera handle the face recognition then pass the information onto the NVR allows you to have face recognition on up to 16 channels simultaneously.
Like our other TVT IP cameras set-up is easy with simple plug and play to the TVT recorders.
| TD-9585E3B-2812-B/W | |
|---|---|
| Image | |
| Max. Resolution | 8MP (3840 x 2160) @ 30fps |
| Lens Type | 2.8-12mm Motorised Varifocal |
| Field of View | Vertical: 54~17° / Horizontal: 102~32° |
| Image Sensor | 1/2.8" CMOS |
| Supported Resolutions | 8MP (3840 x 2160) / 6MP (3072 x 2048) / 5MP (2592 × 1944) / 4MP (2592 × 1520) / 2K (2560 × 1440) / 3MP (2304 × 1296) / 1080P (1920 × 1080) / 720P (1280 × 720) / D1 / VGA (640 × 480) / 480 × 240 / CIF |
| Illumination | |
| Min. Illumination | Colour: 0.015lux @ F1.4 (AGC On) B/W: 0 lux (IR On) |
| IR Range | Up to 50m |
| White Light Range | - |
| Day/Night Function | IR Cut Filter with Auto Switch |
| Image Control | |
| Electronic Shutter Speed | 1/3 ~ 1/100000s |
| Wide Dynamic Range | Yes (120dB) |
| BLC | Yes |
| HLC | Yes |
| White Balance | Auto / Manual |
| Digital Noise Reduction | 3D DNR |
| S/N Ratio | ≥50dB |
| Smart Features | |
| AI & Detection | Smart Motion Detection / Line Crossing / Region Intrusion / Abandoned/Missing Object Detection / Loitering Detection / Illegal Parking Detection / Face Detection / Face Recognition / Target Counting / Heat Mapping |
| Privacy Masking | Yes |
| Inputs & Outputs | |
| Video Connection | RJ45 |
| Alarm | - |
| Alarm Connection | - |
| Microphone | Built-in |
| Speaker | - |
| Audio | 1 Input |
| Audio Connection | 3.5mm Socket |
| Storage | Micro SD Card Slot (256GB Max) |
| Encoding & Protocols | |
| Video Compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Audio Compression | G711A/U |
| Bitrate | 64Kbps ~ 12Mbps |
| Bitrate Type | VBR / CBR |
| Protocols | UDP / IPv4 / IPv6 / DHCP / NTP / RTSP / RTP / RTCP / RTMP / PPPoE / DDNS / SMTP / FTP / 802.1x / SNMP / UPnP / HTTP / HTTPS / HTTP POST / P2P / QoS |
| P2P | Yes |
| Onvif | Yes |
| Remote Viewing | |
| Web Client | Chrome (89.0 or later) / Edge (89.0 or later) / Firefox (87.0 or later) / Safari (14.0 or later) |
| Mobile App | Yes |
| Max Users | 10 Simultaneous |
| Power | |
| Input Voltage | 12V DC / PoE |
| Current Consumption | 700mA (Max) |
| Power Connection | 12V - 2.1mm DC Socket / PoE - RJ45 |
| Physical Features | |
| Build | Metal Body |
| Bracket | Deep Base Available |
| Finish | Black or White |
| IP Rating | IP67 |
| Compliance | RoHS 2.0 / REACH / WEEE / Directive 94/62/EC |
| Operating Conditions | -30°C ~ 60°C / Humidity: ≤95% |
| Dimensions | Ø111.6mm x (h) 99.6mm |
