150m RG59+4 PTZ Combo Cable Black

Usually ships the same or next day
(No reviews yet)

Save Time & Money with This 3-in-1 Design, Ideal for PTZ Installs!

  • Video, Power & Data
  • 2 Power Cores - 30 x 0.15mm Copper
  • RG59 0.7mm Solid Copper Core for Long Runs
  • 2 Shielded Data Cores 0.5mm Copper

Our antihum PTZ Combo cable allows you to send power, data and a video signal down just the one cable. Perfect for PTZ installations!

Current Stock:

Our antihum® PTZ Combo cable allows you to send power, data and a video signal down just the one cable. Perfect for PTZ installations! Using 1 cable for all 3 functions saves on installation time, material costs, running out and fixing only one cable instead of three!

We also manufacture it with an extra tough outer sheath and it's often used on building sites because of this.

Antihum® branded PTZ combo cable uses 30 x 0.15mm copper conductors for each of the power cores, TWICE the size of some of our competitor's cores! This means using antihum® cable, you can use it for TWICE the distance compared to our competitors before you get the same volt drop.

Similarly we use a 0.7mm SOLID COPPER core for the Co-ax which means again over the same cable length our video signal is up to 4X as strong as our competitors that use "copper coated" centre conductors. Its also shielded with a glued foil sheath to protect against interference. This also prevents the problem of loose foil shorting to the centre-pin.

The three cables are all contained in one outer sheath and can be easily separated to allow the power cores to be taken to a power source, the data cores to a PTZ controler leaving the RG59 to be crimped for connection to a DVR, camera or monitor. The power cores are 0.15 x 30 (0.5mm sq) stranded to prevent interruptions and are colour coded red 12V and black 0V to avoid any errors in connection. These power cores can also be used to run 24V AC.

The superb performance of our antihum® RG59 cable is no accident and we have had it manufactured to the same exacting standards now for 20 years so you know you will always get consistent high quality images when you use it, even with HD cameras!

Solid Copper Core

Premium quality for longer runs. Not inferior CCS (Copper Coated Steel) or CCA (Copper Coated Aluminium).

Did you know?
Copper is a better conductor of electricity than gold so it is the top choice. Aluminium is only 61% as good as copper so can be a real false economy to fit.

Two Power Cores

Great for powering the camera - 30 x 0.15mm copper.

Two Data Cores

Data cores with shield for sending PTZ control commands. You could even use them for audio instead and add a mic to you camera.

Double Shield

  1. Glued foil means it cuts and stays right to the very edge of the insulator for max protection against interference - that's why we call it antihum®
  2. 0.12 x 48 aluminium wire shield

Quality Cable on Quality Wooden Drums

Antihum® cable is supplied on wooden reels (not cardboard) so they don't fall apart in your van. Saves time - perfect for professional installers!

Key Features

Key Features of our Antihum RG59 Plus 4 PTZ Combo Cable

RG59 Core 0.7mm Solid Copper
RG59 Shield 0.12 x 48 Aluminium Wires
RG59 Foil Bonded Aluminium
Power Cores 2 (Insulated Copper)
Power Core Size 30 x 0.15mm
Power Core Colours Red / Black
Data Cores 2 (Shielded)
Data Core Size 0.5mm
Data Core Colours Yellow / Orange
Impedance 75 ohm
Outer Sheath PVC
Colour Black
Cable Size Ø11mm
Cable Length 150m
Dimensions Drum: Ø300mm x (H) 280mm
