Covert Bolt Co-ax Analogue Camera Module 4.3mm
Covert Module with Bolt-head Lens
- 1/4 Inch Colour CCD
- Unusual Bolt-Head Design Lens
- 350 TVL Resolution
- 12V DC
This miniature colour module measures only 22 x 26mm and is great for building into enclosures or the structure of a building for discrete covert surveillance.
This miniature colour module measures only 22 x 26mm and is great for building into enclosures or the structure of a building for discrete covert surveillance.
The 4.3mm pinhole lens has been cleverly disguised as a bolt-head so the module can easily be mounted behind wall panels or on any enclosure where a bolt might be used. For easy fixing the lens can be unscrewed from the main module and refitted once the module has been positioned behind the surface with a 8mm drilled hole as shown in the diagram. The lens/bolt can then be screwed by hand back onto the module.
The whole module weighs only 9 gms and can easily be fitted to a flat surface with the fixing pads provided.
| CCT698 | |
|---|---|
| Image Sensor | 1/4" Colour CCD |
| Resolution | 350 TVL |
| Lens Type | 4.3mm Pinhole |
| Image Output | 1 Volt Peak-Peak 75 ohm |
| Min. Illumination | 0.2 Lux @ F1.2 |
| Input Voltage | 12V DC |
| Current Consumption | 110mA |
| Video Connection | BNC Socket |
| Power Connection | 2.1mm DC Socket |
| Bracket | Fixing Pads Supplied |
| Finish | Matt Black |
| Build | ABS |
| Cabling | 45cm lead |
| Dimensions | 22mm high x 26mm wide x 20mm deep |
- Technology:
- Co-ax
- Design:
- Covert
- Lens:
- 4.3mm
- Resolution:
- 350 TVL
- Type:
- Camera
