Perfect Choice for Anyone Looking for Good Quality CCTV Recordings At a Budget Friendly Price
- iSENSE Lite Built-in
- Free Remote Setup
- Free Windows, Android & iOS Apps
- Drive Capacity: 6TB Max (1TB Supplied)
Previous code: LITE008A is now DVR108-01A
Previous code: LITE016B is now DVR116-01B
The 2MP Lite is just that, a basic model for budget installs that don't require the highest resolution possible.
Easy to use and install DVR
...now supports Cloud storage
- iSENSE Lite Built-in
- Hi-res 2MP Recording
- Free Android & iOS Apps
- Free Windows Software
- Instant Detective Search
- Self Password Reset (Free)
- Free UK Managed DDNS
- Free Remote Setup
- Face Detect (with iSENSE)
- Vehicle Detect (with iSENSE)
- Rapid Deploy Cam. Compatible
- Add up to 8 IP Cameras
- Tri-Stream TX (Full-Sub-Mobile)
- Dual Stream Record (Main & Sub)
- Email Password Reminder
- Alarm Event Recording
- Easy Schedule Recording
- Auto Snapshot Capture
- Talk Back Feature
- Video TAG Features
- Email & FTP Built-in
- Cloud Storage
- Covert Camera Mode
- Privacy Masking
- USB Back Up Port
- Records Audio
The DVR is designed to be easy to use and simple to install, packing a punch with features such as "P2P Easy Remote Monitoring" and the latest AI technology under the hood..
All the DVRs have auto-camera inputs so you can use either TVI, CVI, AHD or CVBS cameras and even detect IP cameras on a network for maximum flexibility. Up the Co-ax control (UTC) of the cameras makes installation a doddle on items such as PTZs as you don't need to install a separate data cable for control.
Now with iSENSE firmware, the DVR has cloud storage and even Google integration. For example by saying "Hey Google, show me the front door camera" you could view your CCTV on your Google Nest!! The free mobile app for these models supports live view, search, playback and talkback, but not Push notifcation, it makes the DVR a great choice for installers wanting something different to their peers
The Lite DVR range is a great choice for installers who want to have a genuine Trade Only CCTV product offering that makes them stand out from the crowd, feature packed and competitively priced it means you don't have to compete with DIY offerings as the ZIP is not sold via Retailers. Newly added features requested by installers include a free self-help password reset routine and even easier and faster QR code network set up that doesn't require an account per user - unlike competitor models that harvest your data, we don't.
Lite 2MP DVRs
The 2MP Lite is just that, a basic model for budget installs that don't require the highest resolution possible. The Lite model (like all the range) comes with free software for a PC, free mobile phone apps and a fast and easy to use QR code set up for remote connections.
Not only does the LITE range work with the latest HD technologies (whether TVI, CVI or AHD) it works with IP cameras too as a bonus to the existing channels so there is capacity to expand your system at a later date.
The LITE is still feature packed but has fewer frills than the Supa and Xtreme models using 1080N* recording and being limited to 1 channel of audio but this suits most domestic and smaller commercial installs.
*1080N uses a "Native or Natural" picture creation method instead of "Progressive" as with 1080P hence the name change. It gives the same superb HD quality as 1080P so you can still zoom in on an image but just refreshes in a different way sending a full frame each time. It's also 1080 pixels wide rather than high making it easier to create split screen configurations within CCTV recorders.
DVR108-01A | DVR116-01B | |
---|---|---|
Video Inputs | 8 | 16 |
Video in Connection | BNC Sockets | BNC Sockets |
Compatibility | TVI / CVI / AHD / CVBS / IP | TVI / CVI / AHD / CVBS / IP |
Resolution | 2MP (Max) | 2MP (Max) |
Recording Resolution | 1080N* | 1080N* |
Recording Speed | 15 fps | 15 fps |
Compression | H264 / H265 | H264 / H265 |
Max IP Cameras | 4 x 2MP / 2 x 4MP | 8 x 2MP / 4 x 4MP |
IP Camera Connection | LAN (RJ45) | LAN (RJ45) |
IP Bandwidth | 16MB | 32MB |
Audio Inputs | 1 | 1 |
Audio Input Connection | Phono Socket | Phono Socket |
Audio Output | 1 | 1 |
Audio Out Connection | Phono Socket | Phono Socket |
Alarm Inputs | Via IP Cameras | Via IP Cameras |
Alarm Outputs | Via IP Cameras | Via IP Cameras |
Video Outputs | 2 | 2 |
Video Out Connection | HDMI / VGA | HDMI / VGA |
Hard Drive Slots | 1 | 1 |
Max Drive Capacity | 6TB Max** (1TB Supplied) | 6TB Max** (2TB Supplied) |
HDD Interface | SATA | SATA |
Networkable | Yes | Yes |
Network Connection | RJ45 | RJ45 |
Communication | Coaxitron (UTC) / RS485 | Coaxitron (UTC) / RS485 |
RS485 Interface | Spring Clamp Terminals | Spring Clamp Terminals |
Remote Control | Supplied | Supplied |
Mouse Control | Via USB (Supplied) | Via USB (Supplied) |
USB Backup | Yes | Yes |
Motion Detect | Yes | Yes |
Windows Support | Windows 7 or Later | Windows 7 or Later |
Client Software | Supplied | Supplied |
Power | 12V DC | 12V DC |
Power Connection | 2.1mm DC Socket | 2.1mm DC Socket |
PSU | 2A (Supplied) | 2A (Supplied) |
Dimensions | (H) 53 x (W) 300 x (D) 217mm | (H) 53 x (W) 300 x (D) 217mm |
*1080N uses a "Native or Natural" picture creation method instead of "Progressive" as with 1080P hence the name change. It gives the same superb HD quality as 1080P so you can still zoom in on an image but just refreshes in a different way sending a full frame each time. It's also 1080 pixels wide rather than high making it easier to create split screen configurations within CCTV recorders.
**Our DVRs take the latest 8 and 10TB sizes but we've based our table on a maximum capacity drive size of 6TB as they currently represent the best value for money.
