GEM LITE 8 & 16CH 2MP XVR

Gem
SKU:
DVR108-01A
Availability:
Usually ships the same or next day
(No reviews yet)

Perfect Choice for Anyone Looking for Good Quality CCTV Recordings At a Budget Friendly Price

  • iSENSE Lite Built-in
  • Free Remote Setup
  • Free Windows, Android & iOS Apps
  • Drive Capacity: 6TB Max (1TB Supplied)

Previous code: LITE008A is now DVR108-01A
Previous code: LITE016B is now DVR116-01B

The 2MP Lite is just that, a basic model for budget installs that don't require the highest resolution possible.

Current Stock:

Easy to use and install DVR

...now supports Cloud storage

  • iSENSE Lite Built-in
  • Hi-res 2MP Recording
  • Free Android & iOS Apps
  • Free Windows Software
  • Instant Detective Search
  • Self Password Reset (Free)
  • Free UK Managed DDNS
  • Free Remote Setup
  • Face Detect (with iSENSE)
  • Vehicle Detect (with iSENSE)
  • Rapid Deploy Cam. Compatible
  • Add up to 8 IP Cameras
  • Tri-Stream TX (Full-Sub-Mobile)
  • Dual Stream Record (Main & Sub)
  • Email Password Reminder
  • Alarm Event Recording
  • Easy Schedule Recording
  • Auto Snapshot Capture
  • Talk Back Feature
  • Video TAG Features
  • Email & FTP Built-in
  • Cloud Storage
  • Covert Camera Mode
  • Privacy Masking
  • USB Back Up Port
  • Records Audio



The DVR is designed to be easy to use and simple to install, packing a punch with features such as "P2P Easy Remote Monitoring" and the latest AI technology under the hood..

All the DVRs have auto-camera inputs so you can use either TVI, CVI, AHD or CVBS cameras and even detect IP cameras on a network for maximum flexibility. Up the Co-ax control (UTC) of the cameras makes installation a doddle on items such as PTZs as you don't need to install a separate data cable for control.

Now with iSENSE firmware, the DVR has cloud storage and even Google integration. For example by saying "Hey Google, show me the front door camera" you could view your CCTV on your Google Nest!! The free mobile app for these models supports live view, search, playback and talkback, but not Push notifcation, it makes the DVR a great choice for installers wanting something different to their peers

The Lite DVR range is a great choice for installers who want to have a genuine Trade Only CCTV product offering that makes them stand out from the crowd, feature packed and competitively priced it means you don't have to compete with DIY offerings as the ZIP is not sold via Retailers. Newly added features requested by installers include a free self-help password reset routine and even easier and faster QR code network set up that doesn't require an account per user - unlike competitor models that harvest your data, we don't.

Lite 2MP DVRs

The 2MP Lite is just that, a basic model for budget installs that don't require the highest resolution possible. The Lite model (like all the range) comes with free software for a PC, free mobile phone apps and a fast and easy to use QR code set up for remote connections.

Not only does the LITE range work with the latest HD technologies (whether TVI, CVI or AHD) it works with IP cameras too as a bonus to the existing channels so there is capacity to expand your system at a later date.

The LITE is still feature packed but has fewer frills than the Supa and Xtreme models using 1080N* recording and being limited to 1 channel of audio but this suits most domestic and smaller commercial installs.

*1080N uses a "Native or Natural" picture creation method instead of "Progressive" as with 1080P hence the name change. It gives the same superb HD quality as 1080P so you can still zoom in on an image but just refreshes in a different way sending a full frame each time. It's also 1080 pixels wide rather than high making it easier to create split screen configurations within CCTV recorders.

  DVR108-01A DVR116-01B
Video Inputs 8 16
Video in Connection BNC Sockets BNC Sockets
Compatibility TVI / CVI / AHD / CVBS / IP TVI / CVI / AHD / CVBS / IP
Resolution 2MP (Max) 2MP (Max)
Recording Resolution 1080N* 1080N*
Recording Speed 15 fps 15 fps
Compression H264 / H265 H264 / H265
Max IP Cameras 4 x 2MP /  2 x 4MP 8 x 2MP / 4 x 4MP
IP Camera Connection LAN (RJ45) LAN (RJ45)
IP Bandwidth 16MB 32MB
Audio Inputs 1 1
Audio Input Connection Phono Socket Phono Socket
Audio Output 1 1
Audio Out Connection Phono Socket Phono Socket
Alarm Inputs Via IP Cameras Via IP Cameras
Alarm Outputs Via IP Cameras Via IP Cameras
Video Outputs 2 2
Video Out Connection HDMI / VGA HDMI / VGA
Hard Drive Slots 1 1
Max Drive Capacity 6TB Max** (1TB Supplied) 6TB Max** (2TB Supplied)
HDD Interface SATA SATA
Networkable Yes Yes
Network Connection RJ45 RJ45
Communication Coaxitron (UTC) / RS485 Coaxitron (UTC) / RS485
RS485 Interface Spring Clamp Terminals Spring Clamp Terminals
Remote Control Supplied Supplied
Mouse Control Via USB (Supplied) Via USB (Supplied)
USB Backup Yes Yes
Motion Detect Yes Yes
Windows Support Windows 7 or Later Windows 7 or Later
Client Software Supplied Supplied
Power 12V DC 12V DC
Power Connection 2.1mm DC Socket 2.1mm DC Socket
PSU 2A (Supplied) 2A (Supplied)
Dimensions (H) 53 x (W) 300 x (D) 217mm (H) 53 x (W) 300 x (D) 217mm

*1080N uses a "Native or Natural" picture creation method instead of "Progressive" as with 1080P hence the name change. It gives the same superb HD quality as 1080P so you can still zoom in on an image but just refreshes in a different way sending a full frame each time. It's also 1080 pixels wide rather than high making it easier to create split screen configurations within CCTV recorders.

**Our DVRs take the latest 8 and 10TB sizes but we've based our table on a maximum capacity drive size of 6TB as they currently represent the best value for money.
