ZIP Smart 4, 8 & 16CH 4K NVR PoE
ZIPZip PoE NVRs...
- Stunning Video up to 4K
- Vehicle Detection System
- iSENSE AI Built-in
- Perimeter Intrusion & Line Crossing
This PoE ZIP NVR can power your IP cameras directly so it really couldn't be easier to fit. With its built in LAN boost feature you can have cable runs up to 250M so distance issues are a thing of the past. The iSENSE technology can even tell you how much power each individual camera is taking so you can balance loads.
- Stunning Video up to 4K
- iSENSE AI Built-in
- Free Apps & Software
- 250M LAN Boost
- Built-in PoE Switch
- Free UK Managed DDNS
- Free Remote Setup
- Face Detection & Recognition*
- Vehicle Detection System*
- Perimeter Intrusion
- Alarm Inputs /Output
- ZipStor eSATA Expansion*
- Dual Stream Recording
- Line Crossing*
- Talk Back Feature
- Video TAG features
- Email & FTP Built-in
- Cloud Storage
- Google & Alexa
- Covert Camera Mode
- Privacy Masking
- USB Back Up Port
- Password Reminders
- Records Audio
Fit CCTV with Artificial Intelligence, fit a Zip iSENSE!
For a quick and easy install with excellent features that will satisfy your most demanding customers, make the PoE Zip NVR the heart of your Security Systems.
This recorder can power cameras with out the need for external power supplies, and with the LAN Boost feature capable of increasing cable runs up to 250m, reducing your installation time and costs.
iSense is an AI firmware and when combined with iSense cameras can auto detect people and recognise faces. When your customer is dealing with an incident the iSense AI can be used to search for people within their recorded footage. The Ideal tool that can save your customers time and effort when incidents occur. False alarms can be reduced with the iSense technology able to identify people or vehicles without triggering when an animal or a reflection from sunlight occurs.
Intelligent Dual Stream recording means you can record at 4K and a lower resolution, making remote monitoring lightning fast while you still have detailed 4K video for evidence when you need it. Remote viewing on a phone is easy to setup and use with the ZIPvision Pro app. This tool comes with a range of useful features such as search and playback, instant notifications, face database upload and search, and more. It's designed to be user-friendly, so both experienced installers and less technical users can benefit from it.
Zip NVRs are ONVIF compatible so they will work with 3rd party compatible ONVIF IP cameras. However, different manufacturers have different features. If you want all the iSENSE features choose the ZIP IP iSENSE cameras as you will only get all the features when the ZipNVR is connected to other iSENSE devices. With a wide choice of ZIP IP cameras including a covert module there is a solution for everyone using the superb ZIP range. We recommend the ZIP range for professional CCTV installers as a strong powerful recorder, perfect for their customer security needs.
NVR204-00/B/D/E | NVR208-00/B/D/E | |
---|---|---|
ONVIF Version | 19.12 | 2.6v19.12 |
Compression | H.264 / H.265 | H.264 / H.264+ / H.265 / H.265+ |
Network Interface | RJ45 - 100Mbps | RJ45 - 1000Mbps |
Network Cameras | 4 Max | 8 Max |
PoE Cameras | 4 Max | 8 Max |
PoE Camera Connection | RJ45 | RJ45 |
Resolution | Up to 4K | Up to 4K |
Recording Bandwidth | 4K (8MP) / 5MP / 3MP / 2MP (1080p) / 960 | 128Mbps |
Voice Assistant | Alexa / Google | Alexa / Google |
Face Detection | Yes | Yes |
Face Recognition | Yes | Yes |
Person Detection | Yes | Yes |
Vehicle Detection | Yes | Yes |
Line Crossing | Yes | Yes |
Cloud Storage | DropBox / Google Drive | DropBox / Google Drive |
Audio Inputs | 1 | 1 |
Audio Input Connection | Phono Socket | Phono Socket |
Audio Output | 1 | 1 |
Audio Out Connection | Phono Socket | Phono Socket |
Alarm Inputs | 4 | 8 |
Alarm Input Connection | Screw Terminals | Screw Terminals |
Alarm Outputs | 1 | 1 |
Alarm Output Connection | Screw Terminals | |
Video Outputs | 2 | 2 |
Video Out Connection | 1x HDMI / 1x VGA | 1x HDMI / 1x VGA |
Output Resolution | HDMI - 4K (Max) / VGA - 1080p (Max) | HDMI - 4K (Max) / VGA - 1080p (Max) |
Operating Mode | Triplex (Main / Sub / Mobile) | Triplex (Main / Sub / Mobile) |
Hard Drive Slots | 1 | 1 |
Max Drive Capacity | 6TB | 10TB* (1x 10TB) |
HDD Interface | ATA-100 | ATA-100 |
eSata | eSATA Up To 40TB | Up To 40TB |
Communication | RS485 / RS232 | RS485 |
RS485 Interface | Yes | Screw Terminals |
RS232 Interface | ~ | ~ |
USB Sockets | 2 (2.0) | 3 (1x 3.0 / 2x 2.0) |
USB Backup | Yes | Yes |
Mouse Control | Via USB (Supplied) | Via USB (Supplied) |
Remote Control | Supplied | Supplied |
Covert Camera Setting | Yes | Yes |
PC Client Software | Supplied | Supplied |
Mobile Apps | Androis & iOS (Zip Vision Pro) | Androis & iOS (Zip Vision Pro) |
Power | 48V DC - 1.2A | 48V DC - 2A |
Power Connection | 4 Pin Socket | 4 Pin Socket |
PSU | Supplied | Supplied |
Dimensions | (H) 53 x (W) 300 x (D) 217mm | (H) 53 x (W) 300 x (D) 217mm |
NVR216-00/B/D/E | |
---|---|
ANPR | Yes |
Face Rec | Yes |
HDMI Spot Monitor Out | Yes |
ONVIF Version | 2.6v19.12 |
Compression | H.264 / H.264+ / H.265 / H.265+ |
Network Interface | RJ45 / 1000Mbps |
Cameras | 16 Max (Network) |
PoE Cameras | Yes - 16 Max (RJ45) |
Recording Resolution | 4K / 5MP / 3Mp / 2MP(1080p) / 1.3MP(960p) / 1MP(720p) |
Recording Bandwidth | 256Mbps |
Video Outputs | 1x HDMI / 1x HDMI Spot / 1 x VGA |
Output Resolution | HDMI - 4K (Max) / VGA - 1080p (Max) |
Audio | 1 in 1 out (Phono) |
Alarms | 16 in 1 out (Hardwired) |
Hard Drive* | 40TB max (4x 10TB) |
eSATA (ZipStor) | Yes - 40TB Max |
Serial Interface | RS485 |
Power | 240V AC |
Dimensions | (H) 68 x (W) 377 x (D) 340mm |
