ZIP Smart 4, 8 & 16CH 4K NVR PoE

ZIP
SKU:
GP-NVR204
Availability:
Usually ships the same or next day
(No reviews yet)

Zip PoE NVRs...

  • Stunning Video up to 4K
  • Vehicle Detection System
  • iSENSE AI Built-in
  • Perimeter Intrusion & Line Crossing

This PoE ZIP NVR can power your IP cameras directly so it really couldn't be easier to fit. With its built in LAN boost feature you can have cable runs up to 250M so distance issues are a thing of the past. The iSENSE technology can even tell you how much power each individual camera is taking so you can balance loads.

Current Stock:
  • Stunning Video up to 4K
  • iSENSE AI Built-in
  • Free Apps & Software
  • 250M LAN Boost
  • Built-in PoE Switch
  • Free UK Managed DDNS
  • Free Remote Setup
  • Face Detection & Recognition*
  • Vehicle Detection System*
  • Perimeter Intrusion
  • Alarm Inputs /Output
  • ZipStor eSATA Expansion*
  • Dual Stream Recording
  • Line Crossing*
  • Talk Back Feature
  • Video TAG features
  • Email & FTP Built-in
  • Cloud Storage
  • Google & Alexa
  • Covert Camera Mode
  • Privacy Masking
  • USB Back Up Port
  • Password Reminders
  • Records Audio

Fit CCTV with Artificial Intelligence, fit a Zip iSENSE!

This PoE ZIP NVR can power your IP cameras directly so it really couldn't be easier to fit. With its built in LAN boost feature you can have cable runs up to 250M so distance issues are a thing of the past. The iSENSE technology can even tell you how much power each individual camera is taking so you can balance loads

iSENSE is the new and exciting "artificial intelligence" firmware for the ZIP range of NVRs bringing AI technology to this established and trusted brand. ZipNVRs with iSENSE firmware and ZIP iSENSE cameras can automatically detect people, recognise faces and even compare them in a built in database. You can even upload an image from the phone app and search for video of that person in the recordings. No longer do you need to search through hours of footage looking for people, let ZIP NVR find them in seconds using iSENSE.

With Google & Alexa integration and cloud backup the ZIP is a trade-only NVR that means business and wins business. The new iSENSE firmware can detect vehicles, even distinguish if a car is stationary or moving and trigger events, for example if a car is parked where it shouldn't be, and with iSENSE it's all done automatically.

Using the power of Google and Alexa integration you can for example pull up the video feed from the ZIP on an "Echo Show" using a command like "Alexa, show me my feed from my drive camera" making the ZIP NVR range ideal for the switched on Pro CCTV installers.

False alarms are drastically reduced using iSENSE rather than line crossing or VMD. You can identify the object as a person or vehicle rather than a false trigger from sunshine or animals. You could even identify who it is and trigger only on "unknown people".

Intelligent Dual Stream recording means you can record at 4K and a lower resolution so remote monitoring is lightning fast but you still have stunning 4K video for evidence when you need it.

Remote viewing on a phone is superb with the new ZIPvision Pro app. Fully loaded with features such as search and play, instant notifications, face database upload and search plus lots, lots more! It really is a fantastic tool to satisfy the most sophisticated technophiles.

Zip NVRs are ONVIF compatible so they will work with 3rd party compatible ONVIF IP cameras but different manufacturers have different features. If you want all the iSENSE features choose the ZIP IP iSENSE cameras as you will only get the all the features when the ZipNVR is connected to other iSENSE devices. With a wide choice of ZIP IP cameras including a covert module there is a solution for everyone using the superb ZIP range, well recommended for professional CCTV installers.

  NVR204-00/B/D/E NVR208-00/B/D/E
ONVIF Version 19.12 2.6v19.12
Compression H.264 / H.265 H.264 / H.264+ / H.265 / H.265+
Network Interface RJ45 - 100Mbps RJ45 - 1000Mbps
Network Cameras 4 Max 8 Max
PoE Cameras 4 Max 8 Max
PoE Camera Connection RJ45 RJ45
Resolution Up to 4K Up to 4K
Recording Bandwidth 4K (8MP) / 5MP / 3MP / 2MP (1080p) / 960 128Mbps
Voice Assistant Alexa / Google Alexa / Google
Face Detection Yes Yes
Face Recognition Yes Yes
Person Detection Yes Yes
Vehicle Detection Yes Yes
Line Crossing Yes Yes
Cloud Storage DropBox / Google Drive DropBox / Google Drive
Audio Inputs 1 1
Audio Input Connection Phono Socket Phono Socket
Audio Output 1 1
Audio Out Connection Phono Socket Phono Socket
Alarm Inputs 4 8
Alarm Input Connection Screw Terminals Screw Terminals
Alarm Outputs 1 1
Alarm Output Connection Screw Terminals
Video Outputs 2 2
Video Out Connection 1x HDMI / 1x VGA 1x HDMI / 1x VGA
Output Resolution HDMI - 4K (Max) / VGA - 1080p (Max) HDMI - 4K (Max) / VGA - 1080p (Max)
Operating Mode Triplex (Main / Sub / Mobile) Triplex (Main / Sub / Mobile)
Hard Drive Slots 1 1
Max Drive Capacity 6TB 10TB* (1x 10TB)
HDD Interface ATA-100 ATA-100
eSata eSATA Up To 40TB Up To 40TB
Communication RS485 / RS232 RS485
RS485 Interface Yes Screw Terminals
RS232 Interface ~ ~
USB Sockets 2 (2.0) 3 (1x 3.0 / 2x 2.0)
USB Backup Yes Yes
Mouse Control Via USB (Supplied) Via USB (Supplied)
Remote Control Supplied Supplied
Covert Camera Setting Yes Yes
PC Client Software Supplied Supplied
Mobile Apps Androis & iOS (Zip Vision Pro) Androis & iOS (Zip Vision Pro)
Power 48V DC - 1.2A 48V DC - 2A
Power Connection 4 Pin Socket 4 Pin Socket
PSU Supplied Supplied
Dimensions (H) 53 x (W) 300 x (D) 217mm (H) 53 x (W) 300 x (D) 217mm
  NVR216-00/B/D/E
ANPR Yes
Face Rec Yes
HDMI Spot Monitor Out Yes
ONVIF Version 2.6v19.12
Compression H.264 / H.264+ / H.265 / H.265+
Network Interface RJ45 / 1000Mbps
Cameras 16 Max (Network)
PoE Cameras Yes - 16 Max (RJ45)
Recording Resolution 4K / 5MP / 3Mp / 2MP(1080p) / 1.3MP(960p) / 1MP(720p)
Recording Bandwidth 256Mbps
Video Outputs 1x HDMI / 1x HDMI Spot / 1 x VGA
Output Resolution HDMI - 4K (Max) / VGA - 1080p (Max)
Audio 1 in 1 out (Phono)
Alarms 16 in 1 out (Hardwired)
Hard Drive* 40TB max (4x 10TB)
eSATA (ZipStor) Yes - 40TB Max
Serial Interface RS485
Power 240V AC
Dimensions (H) 68 x (W) 377 x (D) 340mm
Technology:
IP
Type:
Recorder
Resolution:
8MP (4K)
Range:
Smart
Type:
NVR
