Mortice Mount Electric Bolts

Usually ships the same or next day
(No reviews yet)

with Status Output and Adjustable Delay

  • Mortice Mount Design
  • Lock Prevention when Open
  • Adjustable Delay up to 6s
  • 12V DC Operation
The ACC514 has an adjustable delay and status relay output which can be connected to a buzzer or light to produce a visible or audible alert when the door is opened.
Current Stock:

The ACC514 is a feature packed 5 wire electric bolt which means there are 2 wires for connecting the power and 3 extra wires to indicate the door status (N/O, COM, N/C). These additional wires can be connected to a buzzer or light for example to produce a visible or audible alert when a door is opened. This could even be wired into a CCTV system to start a camera recording.

The ACC514 has a built-in adjustable delay which can be set to 0, 3 or 6 seconds to keep the door unlocked for up to 6 seconds after power is restored.

Electric bolts are an efficient method of adding secure access control to a door. By using them in conjunction with one of our exit buttons or wireless key fobs you can limit access to almost any door.

This could be a push to exit button allowing staff to leave through a security door while preventing unauthorised access from the outside or a wireless key fob for secure keyless entry.

An electronic bolt works by holding the door in place as long as there is power being supplied. As soon as the power supply is cut the bolt retracts so that the door can be opened. You would connect the control device and power to the bolt via an access control panel or relay so that the power can be cut when triggered. When powered up again the bolt protrude again locking the door in place.

Another clever feature of the ACC514 prevents the bolt from locking when the door is open. Reed switches in the bolt prevent it from locking until triggered by the magnet in the locking plate fixed to the door frame. This simple but effective solution ensures the bolt will only lock when the door is closed.

Our Handy Rascal relays are ideal for use with our electronic locks as they add extra flexibility and functionality. The HRM100 1ch opto isolating relay would cut power to the lock for as long as the exit button is pressed. To have the door stay open for a short while a HRM200 delay on-off relay could be used to cut power to the lock for up to 20 seconds. For a more advanced solution you might consider using the HRM250 10 function relay. As well as being able to set how long the lock's power is cut for you can also specify a time delay between pressing the exit button and the power being cut. This allows for installations where the exit button isn't situated next to the door.

As the ACC514 needs wiring into the door you might want to consider one of our ACC508 stainless steel, armoured door loops to securely house the wires between the door frame and the door.

If you would prefer a surface mount electric bolt take a look at our ACC516.

Design Mortice Mount
Delay Adjustable: 0 / 3 / 6s
Relay Output NO / COM / NC
Voltage 12V DC / 80mA (Holding)
Peak Current 1A (<1s)
Construction Metal
Dimensions (H) 200 x (W) 34 x (D) 41mm (Bolt)
Electric Bolt
